1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ

    Buy cheap 1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ from wholesalers

    Buy cheap 1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ from wholesalers
    • Buy cheap 1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ from wholesalers

    1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ

    Ask Lasest Price
    Brand Name : A V X
    Model Number : TAJR155M006RNJ
    Certification : Original Part
    Price : Negotiation
    Payment Terms : T/T, Western Union, Paypal, Wechat Pay
    Supply Ability : 1000 Reels per Week
    Delivery Time : 2~5 Working Days (Subjected to availability of Stock)
    • Product Details
    • Company Profile

    1.5uF 6.3V Tantalum Electrolytic Capacitor TAJR155M006RNJ

    TAJR155M006RNJ Cap Tant Solid 1.5uF 6.3V R CASE 20% (2.05 X 1.3 X 1.2mm) Inward L SMD 2012-12 25 Ohm 125°C T/R


    Applications :


    General low power DC/DC and LDO.

    Entertainment / Infotainment systems.

    Height restricted design.


    Technical Specifications :


    MountingSurface Mount
    TypeSolid
    Capacitance Value1.5uF
    Tolerance20%
    Voltage6.3VDC
    ESR (Ohm)25
    Equivalent Series Resistance TypeStandard
    IR (mA)47
    IL (uA)0.5
    PolarityPolar
    Dissipation Factor (%)6
    Fail Safe with Built-in FuseNo
    High Shock and VibratingYes
    Case CodeR
    Case StyleMolded
    ConstructionFlat
    Termination StyleInward L
    Number of Terminals2
    Size (mm)2.05 X 1.3 X 1.2
    Package/Case2012-12
    Temperature Range @ Derated Voltage (°C)85 to 125
    Minimum Operating Temperature (°C)-55
    Maximum Operating Temperature (°C)125
    PackagingTape and Reel
    Product Length (mm)2.05
    Product Depth (mm)1.3
    Product Height (mm)1.2(Max)
    Product Weight (g)0.01

    Key Features :


    General purpose SMT chip tantalum series.

    17 case sizes available, standard and low profiledown to 1mm maximum height.

    CV range: 0.10 - 2200μF / 2.5 - 50V.

    J-lead construction.


    or product datasheet, CONTACT US directly.
