T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor

    Buy cheap T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor from wholesalers

    Buy cheap T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor from wholesalers
    • Buy cheap T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor from wholesalers

    T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor

    Ask Lasest Price
    Brand Name : original
    Model Number : T490A476M010ATE1K2
    Certification : contact us
    Price : 100000+pcs+35 working days
    Payment Terms : T/T,PayPal
    Supply Ability : 10000+pcs+35workings days
    Delivery Time : 25-35 working days
    • Product Details
    • Company Profile

    T490A476M010ATE1K2 47uF 10V Tantalum Electrolytic Capacitor

    T490A476M010ATE1K2

    Specification:
    Capacitance: 47µF
    Tolerance: ±20%
    Voltage-Rating: 10V
    Type: Molded
    ESR (Equivalent Series Resistance): 1.2 ohm @ 100kHz
    Working temperature: -55°C ~ 125°C
    Service life at different temperatures: 1000 hours at 125°C
    Installation type: surface mount type
    Package/Shell: 1206 (3216 Metric)
    Size / Dimensions: 0.126" long x 0.063" wide (3.20mm x 1.60mm)
    Height-Installation (Maximum): 0.071" (1.80mm)
    Manufacturer Part Number: T490A476M010ATE1K2
    Description: 47.0UF 10.0V
    Compliance with the Restriction of Hazardous Substances Directive (RoHS): Meet the requirements of the Restriction of Hazardous Substances Directive (RoHS3)
    Moisture Sensitivity Level (MSL): 1 (unlimited)
    Detailed description: 47µF-molded-tantalum capacitor-10V-1206 (3216-metric)-1.2-ohm-@-100kHz


    The T490 Series, designed for customer product applications (low temperature demanding applications), meets RoHS compliance with leads constructed of 100% matte tin and green molding compound. This series is classified as MSL (Moisture Sensitivity Level) 1 under J STD 020: unlimited floor life time at ≤30°C / 85% RH. Tin/lead (Sn/Pb) terminations are available upon request for any part number. Gold-plated terminations are also available for use with conductive epoxy attachment processes. Standard packaging of these devices is tape and reel in accordance with EIA 481. This system provides perfect compatibility with all tape-fed placement units.

    Key Features:

    • Case Size A
    • Taped and reeled per EIA 481
    • Symmetrical compliant terminations
    • Optional gold-plated terminations
    • Laser-marked case
    • Suitable for 3 x 260°C reflow passes
    • Halogen-free epoxy
    • Capacitance values of 47 μF to 470 μF
    • Tolerance of ±20%
    • Voltage rating of 4 - 10 VDC
    • 0.2% per 1,000 hours at 85ºC 0.5 VR Reliability
    • Small and low profile case sizes
    • RoHS Compliant and lead-free terminations
    • MSL Reflow Temp ≤ 260ºC = 1
    • Operating temperature range of -55˚C to +40˚C
